KGRA 24V 300MM 2000N IP65 Linear Motor with Hall Sensor
The KGRA linear motor has a capacity of 2000N and a travel speed of 7.2mm per second. Limit switches located at the start and end points prevent high current draw and reduce strain on the motor when reaching these points.
KGRA linear motors include a Hall sensor. This makes it suitable for use in areas where precise positioning is required.
Features:
- Supply Voltage: 24V DC
- Force: 2000N
- Speed: 7.2mm/s
- Movement Distance: 300mm
- Limit Switch: Yes
Cable Connections:
- Red: +24V
- Black: GND -24V
- Yellow: +5V
- White: GND
- Brown: H1
- Green: H2
