Out Of Stock
Notify me when its in stockProduct Features
| Step Angle | 0.9° or 1.8° ± 5% |
| Temperature Limit | Max. 80°C |
| Operating Temperature Range | -20°C / 50°C |
| Insulation Resistance | 100MO min. 500V DC |
| Dielectric Resistance | 500V AC/ 1 min |
| Model | Motor Width | Holding Torque | Number of Connections | Current Drawn per Phase | Phase Resistance Value | Phase Inductance Value | Rotor Inertia | Trigger Torque | Shaft Ød | Motor Weight | |
| (mm) | (N·cm) | (A) | (O) | (mH) | (g·cm2) | (N·cm) | (mm) | (kg) | |||
| 42BYGH | B | 26 | 12 | 4 | 0.8 | 7.9 | 7.5 | 21 | 1.37 | 5 | 0.17 |
| 42BYGH | B | 26 | 11 | 4 | 0.5 | 10.3 | 11.5 | 21 | 1.37 | 5 | 0.17 |
