12-40V 10A Motor Driver Card (400W)
PWM speed controlled motor driver for use with your 12-40V DC motors. It can be used with DC motors drawing up to 10A.
Technical Specifications:
-
Operating voltage: 12-40V
-
Operating power: 0.01 - 400W
-
Idle current draw: 0.02A
-
PWM pulse width modulation range: 10% - 100%
-
PWM Frequency: 13 KHz
-
Dimensions: 73 x 60 x 27 mm
-
Reverse voltage and overcurrent protection
