X1040 40A 9-60V PWM DC Motor Speed and Direction Controller

Product Description

The X1040 40A 9-60V PWM DC Motor Controller is designed to control both the speed and rotation direction of DC motors using PWM technology.

Built with high-quality components, the controller provides durable and reliable performance for demanding motor control applications. It supports 9-60V DC motors and allows precise speed adjustment.

A built-in direction control switch allows users to easily change the motor rotation direction or stop the motor.

Switch positions:

• "I" position: Forward rotation

• "O" position: Stop

• "II" position: Reverse rotation

Using PWM (Pulse Width Modulation) technology, the module provides efficient and precise motor speed control while maintaining high motor performance.

It is widely used in robotics, automation systems, electric vehicle projects, and industrial motor control applications.

Applications

• DC motor speed control systems

• Robotics projects

• Industrial automation

• Electric vehicle systems

• DIY electronics projects

Technical Specifications

Electrical Specifications

• Model: X1040

• Input Voltage: 9-60V DC

• Peak Current: 40A

• Continuous Current: 24A

Physical Specifications

• Dimensions: 99 × 60 × 90 mm
